The edwards 88-100 transformer is a heavy-duty power transformer for fire alarm and signaling systems. First, it converts 120 VAC line power to low-voltage output. In addition, it offers dual secondary ratings for flexible installs. As a result, one part covers several notification power needs.
edwards 88-100 transformer specifications
The primary side accepts 120 VAC at 50/60 Hz. Then the secondary delivers two options. Specifically, it provides 24 VAC at 100 VA, or 12 VAC at 50 VA. The unit includes mounting holes for surface installation.
- Primary: 120 VAC, 50/60 Hz
- Secondary: 24 VAC @ 100 VA, or 12 VAC @ 50 VA
- Mounting: surface-mount holes provided
- Series: Edwards 88 heavy-duty transformers
Typical applications
Installers use the 88-100 to power signaling and notification loads. For example, it serves bells, horns, and auxiliary devices. However, match the secondary voltage to your load before wiring. Note that this item is currently out of stock.
For more information, contact the Life Safety Consultants team at 1-888-557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 5.5 lbs |
|---|---|
| Dimensions | 7 × 4.5 × 4.5 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Strobe |
