The Honeywell ZNAC-PS is an optional Class A output converter module. It works with Fire-Lite PS Series power supplies. As a result, it upgrades notification circuits to Class A wiring.
Specifically, the module mounts to connector J8 on the power supply board. In addition, it converts Class B circuits to Class A. Therefore, you gain Class A supervision without losing any circuits.
Honeywell ZNAC-PS Class A Conversion
First, the ZNAC-PS supports the FL-PS6 and FL-PS10 power supplies. Then it enables Class A operation on the outputs. As a result, installers meet projects that require Class A notification wiring.
Furthermore, two slide switches set each output’s function. Therefore, you can configure circuits #1 and #2 for NAC or auxiliary power. The module installs directly onto the existing board.
Key Features
- Optional Class A output converter for PS Series power supplies
- Compatible with the FL-PS6 and FL-PS10
- Converts Class B circuits to Class A without losing circuits
- Mounts to connector J8 on the power supply board
- Two slide switches configure outputs #1 and #2
- Supports NAC or auxiliary power operation
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 1 lbs |
|---|---|
| Dimensions | 12.5 × 9.5 × 4 in |
| Condition | New |
| Manufacturers | Honeywell |
| Part Type | Module |
